BE Mulcher
Specialized mulchers for green spaces
For the shredding of green spaces, parks and gardens.The Nobili BE 14 – 16 – 18 - 20 mulchers are tractor-mounted machines to be fitted to the three-point linkage of both front and rear tractor lifts. Suitable for tractors with power ranging between 35 and 65 HP. The BE series combines compact design with a professional concept, underlined by innovative construction solutions and the use of special materials to reduce the weight. For instance the multi-purpose chassis with the possibility to fit a 2-point-fixed headstock or a headstock with hydraulic offset and the possibility to run at the PTO with 540 or 1000 rpm for a rear or a front mount linkage to the tractor. The BE range is also equipped with the new patented Nobili hammer on bushing. Thanks to its reinforced and protruding part, conceived to create an enlarged abutment surface thus avoiding damage in case of an accidental shock on the rotor tube, this new hammer ensures a high resistance and a very long life service. The mulcher is constructed in compliancewith the European regulations.
Technical features | BE 14 | BE 16 | BE 18 | BE 20 | |
---|---|---|---|---|---|
Connecting position | Reversibile | Reversibile | Reversibile | Reversibile | |
Lateral displacement | mm | 390 - 1020
670 - 740 |
490 - 1120
770 - 840 |
505 - 1305
955 - 855 |
605 - 1405
1055 - 955 |
Working width | mm | 1400 | 1600 | 1800 | 2200 |
Engine speed pdp | rpm | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 |
Tractor horse power | HP | 35-65 | 40-65 | 45-65 | 50-65 |
KW | 26-48 | 29-48 | 33-48 | 37-48 | |
Rotor speed | rpm | 2218 - 2339 | 2218 - 2339 | 2218 - 2339 | 2218 - 2339 |
Blades | 01 | 40 | 48 | 56 | 64 |
06 | 20 | 24 | 28 | 32 | |
Measures | A | 1600 | 1800 | 2000 | 2200 |
B | 980 | 980 | 980 | 980 | |
C | 435 | 435 | 435 | 435 | |
Weight | KG | 335 | 370 | 410 | 455 |
