BP serie 100 Mulcher
Multi-purpose mulcher
For the shredding on green areas, grassy cultivation, corn and bushes.BP mulchers are tractor-mounted machines to be fitted to the three-point linkage of the rear tractor lift. Ideal to shred grass, bushes, pruning, corn and for the maintenance of wide green areas and fallow lands. Multi-purpose and sturdy, BP mulchers are supported by a roller or wheels adjusting the working height. The BP range is equipped with a rotor with eight rows of knife supports and two counter-knives that, together with the roller position, provide the best cut and the reduction of the power absorption. The BP series 10 are available both with fixed coupling and with hydraulic offset, while the BP series 100 are equipped with a strong hydraulic offset. The BP series 1000, in combination with the BPR 280 and BPR 305 models, guarantee high productivity both with front PTO and reverse drive tractors. Nobili mulchers are built in compliance with European regulations.
Technical features | BP 240 | BP 280 | BP 305 | |
---|---|---|---|---|
Connecting position | Rear | Rear | Rear | |
Lateral displacement | mm | 1187 - 1187
607 - 1767 |
1397 - 1397
816 - 1977 |
1517 - 1517
937 - 2097 |
Working width | mm | 2374 | 2793 | 3034 |
Engine speed pdp | rpm | 540/1000 | 540/1000 | 540/1000 |
Tractor horse power | HP | 80-175 | 90-175 | 100-175 |
KW | 59-129 | 66-129 | 74-129 | |
Rotor speed | rpm | 1833/1960 | 1833/1960 | 1833/1960 |
Pruning residues | < | < 5 cm | < 5 cm | < 5 cm |
Blades | 01 | 48 | 56 | 64 |
06 | 24 | 28 | 32 | |
Measures | A | 2548 | 3100 | 3343 |
B | 1290 | 1290 | 1290 | |
C | 525 | 525 | 525 | |
Weight | KG | 820 | 900 | 950 |
