VKD Mulcher
Specialized mulchers for vineyards and orchards
This series of mulchers may be used either for full-feld cultivation, on corn and straw, as well as for shredding grass and even thick pruning residues. The mulchers VKD 155 - 170 - 190 - 210 and 230 are characterized by interchangeable knives and mechanical or hydraulic axial side shift. The high rotation speed of the cutting parts and the presence of three counter-knives allow excellent product shredding.Working widths: 1530 - 1718 - 1906 - 2094 - 2282 mm.
| Technical features | VKD 155 | VKD 170 | VKD 190 | VKD 210 | VKD 230 | |
|---|---|---|---|---|---|---|
| Connecting position | Rear | Rear | Rear | Rear | Rear | |
| Lateral displacement | mm | 765 - 765
405 - 1125 |
859 - 859
404 - 1314 |
953 - 953
503 - 1403 |
1047 - 1047
597 - 1497 |
1141 - 1141
691 - 1591 |
| Working width | mm | 1530 | 1718 | 1906 | 2094 | 2282 |
| Engine speed pdp | rpm | 540 | 540 | 540 | 540 | 540 |
| Tractor horse power | HP | 50-100 | 60-100 | 65-100 | 70-100 | 75-100 |
| KW | 37-74 | 44-74 | 48-74 | 51-74 | 55-74 | |
| Rotor speed | rpm | 2325 | 2325 | 2325 | 2325 | 2325 |
| Pruning residues | < | < 8 cm | < 8 cm | < 8 cm | < 8 cm | < 8 cm |
| Blades | 01 | 32 | 36 | 40 | 44 | 48 |
| 06 | 16 | 18 | 20 | 22 | 24 | |
| Measures | A | 1665 | 1852 | 2040 | 2230 | 2418 |
| B | 1075 | 1075 | 1075 | 1075 | 1075 | |
| C | 510 | 510 | 510 | 510 | 510 | |
| Weight | KG | 510 | 560 | 600 | 640 | 715 |
