BPR serie 100 Mulcher
Multi-purpose reversible mulcher
BPR 180-200-210-220-230-240-280-305 mulchers are tractor-mounted machines with double hitch to be ftted to the tractor three-point-linkage, in front or rear position. Ideal for shredding grass, bushes, pruning and for large grassy areas as well as set-aside maintenance. Multipurpose and robust, BPR mulchers are available with hydraulic offset and are supported by a roller adjusting the working height. The roller cleaning is given by the cutting tools of the powerful 8-row rotor. BPR range is equipped with a rear adjustable plate that, together with the advantageous roller position, ensures a perfect cutting and a power requirement reduction. BPR 280-305 PRO version offers high performance when connected to high HP tractors.BPR mulchers have working widths from 1990 to 3034 mm and a wide selection of interchangeable knives with different shape and size to meet any work need. Available also in left hand version.
Technical features | BPR 180 | BPR 200 | BPR 210 | BPR 220 | BPR 230 | BPR 240 | BPR 280 | BPR 280 PRO | BPR 305 | BPR 305 PRO | |
---|---|---|---|---|---|---|---|---|---|---|---|
Connecting position | Reversibile | Reversibile | Reversibile | Reversibile | Reversibile | Reversibile | Reversibile | Reversibile | Reversibile | Reversibile | |
Lateral displacement | mm | 1017-783
567-1233 |
943-1047
467-1567 |
1047-1047
467-1567 |
1067-1083
547-1603 |
1078-1187
498-1767 |
1187-1187
607-1767 |
1397-1396
816-1977 |
1397-1396
816-1977 |
1517-1517
937-2097 |
1517-1517
937-2097 |
Working width | mm | 1800 | 1990 | 2095 | 2150 | 2260 | 2374 | 2793 | 2793 | 3034 | 3034 |
Engine speed pdp | rpm | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
Tractor horse power | HP | 60-150 | 65-150 | 70-150 | 72-150 | 75-150 | 80-150 | 90-175 | 95-230 | 100-175 | 110-230 |
KW | 44-110 | 48-110 | 51-110 | 53-110 | 55-100 | 59-110 | 66-129 | 70-169 | 74-129 | 81-169 | |
Rotor speed | rpm | 1833/1960 | 1833/1960 | 1833/1960 | 1833/1960 | 1833/1960 | 1833/1960 | 1833/1960 | 1748/1870 | 1833/1960 | 1748/1870 |
Pruning residues | < | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm |
Blades | 01 | 44 | 44 | 44 | 48 | 48 | 48 | 56 | 56 | 64 | 64 |
06 | 22 | 22 | 22 | 24 | 24 | 24 | 28 | 28 | 32 | 32 | |
08 | 44 | 44 | 48 | 48 | 56 | 56 | 64 | 64 | |||
09/L | 22 | 22 | 24 | 24 | 28 | 28 | 32 | 32 | |||
012 | 44+22 | 44+22 | 48+24 | 48+24 | 56+28 | 56+28 | 64+32 | 64+32 | |||
Measures | A | 2000 | 2320 | 2405 | 2350 | 2440 | 2548 | 2998 | 2998 | 3343 | 3343 |
B | 1290 | 1290 | 1290 | 1290 | 1290 | 1290 | 1290 | 1290 | 1290 | 1290 | |
C | 525 | 525 | 525 | 525 | 525 | 525 | 525 | 525 | 525 | 525 | |
Weight | KG | 830 | 850 | 930 | 890 | 930 | 950 | 1020 | 1150 | 1100 | 1230 |
